GSE Digital temperature, vacuum and min. fan speed 2x1A

Digital temperature, vacuum and min. GSE speeds are used to maintain a stable climate in growing rooms or operations with intensive ventilation. Used in combination with exhaust and supply fan. A stable difference between the value of supply and exhaust air ensures a constant vacuum, which prevents the escape of undesirable odors.

Using the four knobs, you can easily set the desired temperature, minimum speed or pressure in the room. The waterproof device with a high degree of protection IP54 is equipped with a sensor for measuring the temperature on a 4 meter cable.

The temperature can be set in the range of 20-30 ° C, fan operation in the range of 20-100% of power. Vacuum from 100% to -50%. The temperature sensor measures with an accuracy of 0.5 ° C. Dimensions 160x100x90. This GSE regulator is designed for 2A / 2x200W / TRIAK 2x16A

Sizes and technical data's:

Case: WxHxD = 130x80x70mm

Controller: WxHxD = 160x100x90mm

Designed for: 2A / 2x200W / TRIAC 2x16A

Volts: 230V / 50HZ

Digital sensor 5V Measures temperatures from –55 ° C to + 125 ° C (–67 ° F to + 257 ° F)

0.5 ° C accuracy from -10 ° C to + 85 ° C

Protection class IP54

Settings range:

Temperature: 20C ° to -30C °

Minimum speed: off, 20% to -100%

Negative pressure: 100% to -50%
